Listing date：2018-01-01 Updated version：V1.01 Status：On Saling

Applications

•Office space: Business buildings, government agencies, etc.

•Science and education units: Universities, research institutes, kindergartens, libraries, museums, etc.

•Commercial service places: Supermarkets, business buildings, hotels, banks, convention centers, etc.

•Leisure and entertainment venues: Stadiums, parks, scenic spots, playgrounds, leisure clubs, etc.

•Transportation stations: Bus stations, railway stations, high-speed rail stations, subway stations, ferries, airports, etc.

Specification

•Assembly: Chassis, movement, control board and power supply

•Housing: Brushed stainless steel, SUS304

•Dimensions: L420*W330*H980mm

•Turntable steering: One-way/two-way

•Movement: Motor or solenoid valve

•Opening time:0.2 seconds

•Anti-reverse: Anti-reverse function to ensure one card per person

•Input::AC220V±10%,50Hz±4%, automatically converted to the working voltage of the Turnstile DC24VDC12V

•Environment: Indoor and outdoor recommended rainproof shed

•Operating temperature: -10℃～60℃

•Relative humidity: 5% ～95%, no condensation

•Speed:>30 people / minute, the indicator light shows

•Working noise:<50DB

•Drop arm length: 500mm

•Aisle Width:550mm

•Weight:45kg

•Input interface: Dry contact signal, 12V level or 12V pulse width ≥100ms

•Communication Interface:RS485 (distance ≤1200 meters), TCP/IP

Specification

·Assembly: Chassis, movement, control board and power supply

·Housing: Brushed stainless steel, SUS304

·Dimensions: L420*W330*H980mm

·Turntable steering: One-way/two-way

·Movement: Motor or solenoid valve

·Opening time:0.2 seconds

·Anti-reverse: Anti-reverse function to ensure one card per person

·Input::AC220V±10%,50Hz±4%, automatically converted to the working voltage of the Turnstile DC24VDC12V

·Environment: Indoor and outdoor recommended rainproof shed

·Operating temperature: -10℃～60℃

·Relative humidity: 5% ～95%, no condensation

·Speed:>30 people / minute, the indicator light shows

·Working noise:<50DB

·Drop arm length: 500mm

·Aisle Width:550mm

·Weight:45kg

·Input interface: Dry contact signal, 12V level or 12V pulse width ≥100ms

·Communication Interface:RS485 (distance ≤1200 meters), TCP/IP
