QR500BLE can be easily disinfected in areas where hygiene is important, and has an exceptionally long life due to no moving parts. The unit resists the elements such as glue, oil, rain, ice, snow. Ideal for hospitals, industrial and commercial application.
This dual-application product has advanced reader features for wide compatibility with different controller types
Specifications
| Maximum read range | 50mm (2.00 in.) |
| Modulation | ASK at 13.56MHz |
| Compatible cards | Mifare S50, S70, KK1208M1, CPU, DesFire, ISO14443A |
| Output | OSDP & Wiegand |
| Operating Voltage | 7-12VDC |
| Operating Current | ≤100mA |
| Standby Current | ≤80mA |
| Working Temperature | -30°C to 65°C (-22°F to 150°F) |
| Operating Humidity | 0 to 95% |
| LED Control Input | RS485 protocol |
| Buzzer Control Input | RS485 protocol |
| Dimensions | 86mm L x 86mm W x 21mm |
| Weight | 290g |
